550 kW
Single electric motor · VFD-driven
← Back to rigs Rig
XDR 160 Electric
The world's fastest electric workover rig. Zero emissions.
Electric · 550 kW VFD · Battery-regen option
Zero
Emissions on the platform
EU
Road-legal · no escorts or permits
1ˢᵗ
Electric workover rig sold into Europe
Why it exists
Onshore workover has been historically slow to electrify because crews refuse to give up performance for ESG points. The XDR 160 Electric breaks that tradeoff: a single 550 kW VFD-driven motor delivers full hookload and line speed with zero emissions on the platform, an optional hybrid battery pack to capture regeneration, and an EU-road-legal tri-axle carrier that gets it on site without escorts or permits.
XDR has sold this platform into the European onshore market — a first for electric workover.
What ships with it
The Electric Rig Package includes the Range 3 Electric Catwalk — fully standalone, with its own onboard electric drive, so the catwalk doesn’t depend on rig power.
Features
Engineered to integrate
- 01Single 550 kW electric motor drives all rig systems — no diesel engine on the platform.
- 02VFD-controlled for precise, smooth torque delivery across the full operating range.
- 03Onboard braking resistors dissipate energy cleanly — no external cooling modules.
- 04Low noise, low maintenance, zero emissions — ideal for ESG-driven operators.
- 05Optional hybrid battery pack captures regenerative power during operations.
- 06Complete package includes standalone Range 3 Electric Catwalk — no rig power needed.
- 07Steerable tri-axle system designed for tight, congested well sites.
- 08Road-legal across the EU without escorts or special permits.
- 09Integrated diagnostics + remote monitoring — field issues surfaced in real time.
- 10Drawn from XDR's proven technology base — higher uptime, lower NPT per well.
Specifications
The numbers, in detail.
Power
- Drive
- Single 550 kW electric motor · VFD-controlled
- Energy recovery
- Onboard resistors · controlled dissipation · optional battery regen
- Emissions
- Zero on platform
Mast & loads
- Hookload
- 160,000 lb
- Mast
- Patented freestanding · API 4F
- Auto lift-capability reduction
- Engaged at mast-angle threshold
Control
- Operating system
- XDR Xenon · SIL 2
- Diagnostics
- Integrated remote monitoring — telemetry to engineering
Mobilisation
- Carrier
- Steerable tri-axle · EU road-legal
- Permits
- In-gauge · no escort or permits required
- Use cases
- Mature fields · urban pads · restricted-access sites
Catwalk
- Catwalk
- Range 3 Electric — standalone, no rig power required
Gallery
In the field.
Talk to us
Spec the XDR 160 Electric for your operation.
Tell us about the wells you service. We'll come back with a configuration, lead time and a service plan.
